ISUZU D-MAX SINGLE CABIN

MY19_D-MAX 250_HO_DC_MID-AB_4X4_RHD_3QFL_DSC2845_edited.png

ISUZU D-MAX DOUBLE CAB

ISUZU D-MAX
SINGLE CAB 1.9L


ISUZU D-MAX
DOUBLE CAB LS


ISUZU DMAX
DC 3.0 Ddi 4X4 LSE A/T

MEDIUM DUTY TRUCKS

FRR 90N

Payload

7 Tons

7th Generation F Series Brochure -4.jpg

FTR 90L NSD

Payload

9 Tons


FTR 90L Non-lsd

Payload

9 Tons


FTS 34l

Payload

8 Tons


Fvr 90L

Payload

11 Tons

ISUZU FLIER FVR90_23052022-1 copy_edited.jpg

Load Body Length

Displacement

Engine Type

Max Output

Max Torque

Cab to Chassis End

Diesel

Manual

hp (kW) @ rpm

Nm (kW) @ rpm

5335 mm

7790 cc

6 Cylinder, Common Rail Turbo-Intercooler

240 hp (177 kW) @ 2,400 rpm

706 hp (72 kW) @ 1,450 rpm

The Isuzu F Series line up incorporates an innovative design, versatility and dependable performance that are vital to success and meets the demands of the operators. Local distributors, construction companies and businesses count on Isuzu F Series Trucks, to deliver MORE value cost effectively, so you have a solid competitive edge in today’ s dynamic business environment. Every businessman wants to optimize payload per trip. What better way to do this with a rigid chassis and optimal wheelbase dimensions in the 7th Generation F series trucks. As they cover the distance, they are engineered to handle heavy loads and a broad variety of rear bodies.

ISUZU FTS 4x4 SPECIFICATIONS

Tyre Size

9R20-14PR

Axle Layout

4x4

Operation

Power

Tilt

Standard

Engine

Diesel 6 Cylinder, Common-Rail, Turbocharged with Intercooler

Tiltable cabin

Standard

Brakes

Drum Brakes

Front Suspension

Multi Leaf Spring Shock Absorbers - Double acting

Rear Suspension

Multi Leaf Spring with Helper Spring

Parking brakes

Yes

Seat Type

Standard

Cabin type

Tilt Cabin Construction

Fuel Tank Capacity (litres)

200

Gross Weight

13000kg

Overall Height

2910 mm

Overall Length

7405 mm

Payload

8000 kg

Overall Width

2400 mm

Wheelbase

4250  mm

Fuel Type

Diesel

Displacement

7790 cc

Max Output hp (kW) @ rpm

240 bhp (170 kW) @ 2,400 rpm

Max Torque Nm (Kgm) @ rpm

706 hp (72 kW) @ 1,450 rpm

Load Body Length

Displacement

Engine Type

Max Output

Max Torque

Cab to Chassis End

Diesel

Manual

hp (kW) @ rpm

Nm (kW) @ rpm

5335 mm

5193 cc

4 Cylinder, Common Rail Turbo-Intercooler

210 hp (154 kW) @ 2,600 rpm

705 Nm (72 kW) @ 1,600 rpm

The Isuzu F Series line up incorporates an innovative design, versatility and dependable performance that are vital to success and meets the demands of the operators. Local distributors, construction companies and businesses count on Isuzu F Series Trucks, to deliver MORE value cost effectively, so you have a solid competitive edge in today’ s dynamic business environment. Every businessman wants to optimize payload per trip. What better way to do this with a rigid chassis and optimal wheelbase dimensions in the 7th Generation F series trucks. As they cover the distance, they are engineered to handle heavy loads and a broad variety of rear bodies.

ISUZU FTR 90L NON-LSD SPECIFICATIONS

Tiltable cabin

Yes

Brakes

Drum Brakes

Front Suspension

Multi Leaf Spring Shock Absorbers - Double acting

Rear Suspension

Multi Leaf Spring with Helper Spring

Cabin type

Tilt Cabin Construction

Sleeper Cab

Standard

Parking brakes

Yes

Seat Type

Standard

Tyre Size

11R22.5-16PR

Axle Layout

4x2

Operation

Power

Tilt

Standard

Fuel Tank Capacity (litres)

200

Gross Weight

14200kg

Overall Height

2720 mm

Overall Length

7405 mm

Payload

xxxx

Overall Width

2400 mm

Wheelbase

4250  mm

Engine

Diesel 4 Cylinder, Common-Rail, Turbocharged with Intercooler

Fuel Type

Diesel

Displacement

5193 cc

Max Output hp (kW) @ rpm

240 bhp (177 kW) @ 2,600 rpm

Max Torque Nm (Kgm) @ rpm

705 hp (72 kW) @ 1,450 rpm

Load Body Length

Displacement

Engine Type

Max Output

Max Torque

Cab to Chassis End

Diesel

Manual

hp (kW) @ rpm

Nm (kW) @ rpm

5335 mm

5193 cc

4 Cylinder, Common Rail Turbo-Intercooler

190 hp (140 kW) @ 2,600 rpm

510 Nm (52 kW) @ 1,600 rpm

The Isuzu F Series line up incorporates an innovative design, versatility and dependable performance that are vital to success and meets the demands of the operators. Local distributors, construction companies and businesses count on Isuzu F Series Trucks, to deliver MORE value cost effectively, so you have a solid competitive edge in today’ s dynamic business environment. Every businessman wants to optimize payload per trip. What better way to do this with a rigid chassis and optimal wheelbase dimensions in the 7th Generation F series trucks. As they cover the distance, they are engineered to handle heavy loads and a broad variety of rear bodies.

ISUZU FTR 90L NSD SPECIFICATIONS

Tiltable cabin

Standard

Brakes

Air Over Hydraulic Dual Circuit

Front Suspension

Multi Leaf Spring Shock Absorbers - Double acting

Rear Suspension

Multi Leaf Spring with Helper Spring

Parking brakes

Yes

Seat Type

Standard

Fuel Tank Capacity (litres)

200

Gross Weight

13500kg

Overall Height

2720 mm

Overall Length

7405 mm

Payload

9000 kg

Overall Width

2400 mm

Wheelbase

4250  mm

Tyre Size

11R22.5-16PR

Axle Layout

4x2

Operation

Power

Tilt

Standard

Engine

Diesel 4 Cylinder, Common-Rail, Turbocharged with Intercooler

Fuel Type

Diesel

Displacement

5193 cc

Max Output hp (kW) @ rpm

190 bhp (140 kW) @ 2,600 rpm

Max Torque Nm (Kgm) @ rpm

510 hp (52 kW) @ 1,600 rpm

Load Body Length

Displacement

Engine Type

Max Output

Max Torque

Cab to Chassis End

Diesel

Manual

hp (kW) @ rpm

Nm (kW) @ rpm

5335 mm

5193 cc

4 Cylinder, Common Rail Turbo-Intercooler

154 hp (210 kW) @ 2,600 rpm

705 Nm (72 kW) @ 1,450 rpm

The Isuzu F Series line up incorporates an innovative design, versatility and dependable performance that are vital to success and meets the demands of the operators. Local distributors, construction companies and businesses count on Isuzu F Series Trucks, to deliver MORE value cost effectively, so you have a solid competitive edge in today’ s dynamic business environment. Every businessman wants to optimize payload per trip. What better way to do this with a rigid chassis and optimal wheelbase dimensions in the 7th Generation F series trucks. As they cover the distance, they are engineered to handle heavy loads and a broad variety of rear bodies.

ISUZU FVR 90L SPECIFICATIONS

Tiltable cabin

Standard

Brakes

Drum Brakes

Front Suspension

Multi Leaf Spring Shock Absorbers - Double acting

Rear Suspension

Multi Leaf Spring with Helper Spring

Cabin type

Tilt Cabin Construction

Sleeper Cab

Standard

Parking brakes

Yes

Seat Type

Standard

Fuel Tank Capacity (litres)

200

Gross Weight

15,000kg

Overall Height

2720 mm

Overall Length

8505 mm

Payload

11,000 kg

Overall Width

2400 mm

Wheelbase

5050  mm

Tyre Size

11R22.5-16PR

Axle Layout

4x2

Operation

Power

Tilt

Standard

Engine

Diesel 6 Cylinder, Common-Rail, Turbocharged with Intercooler

Fuel Type

Diesel

Displacement

7790 cc

Max Output hp (kW) @ rpm

117 bhp (240kW) @ 2,400 rpm

Max Torque Nm (Kgm) @ rpm

706 hp (72 kW) @ 1,450 rpm

Load Body Length

Displacement

Engine Type

Max Output

Max Torque

Cab to Chassis End

Diesel

Manual

hp (kW) @ rpm

Nm (kW) @ rpm

6089 mm

5193 cc

4 Cylinder, Common Rail Turbo-Intercooler

190 hp (140 kW) @ 2,600 rpm

510 Nm (52 kW) @ 1,600 rpm

The Isuzu F Series line up incorporates an innovative design, versatility and dependable performance that are vital to success and meets the demands of the operators. Local distributors, construction companies and businesses count on Isuzu F Series Trucks, to deliver MORE value cost effectively, so you have a solid competitive edge in today’ s dynamic business environment. Every businessman wants to optimize payload per trip. What better way to do this with a rigid chassis and optimal wheelbase dimensions in the 7th Generation F series trucks. As they cover the distance, they are engineered to handle heavy loads and a broad variety of rear bodies.

ISUZU FRR 90N SPECIFICATIONS

Tiltable cabin

No

Brakes

Drum Brakes

Parking brakes

Yes

Seat Type

Standard

Front & Rear Suspension

​Multi-Leaf Spring with double acting telescopic shock absobers

Fuel Tank Capacity (litres)

200

Gross Weight

11000kg

Overall Height

2600 mm

Overall Length

8155 mm

Payload

7000 kg

Overall Width

2200 mm

Wheelbase

4860  mm

Tyre Size

235/75R 17.5

Axle Layout

4x2

Operation

Power

Tilt

Standard

Engine

Diesel 4 Cylinder, Common-Rail, Turbocharged with Intercooler

Fuel Type

Diesel

Displacement

5193 cc

Max Output hp (kW) @ rpm

190 bhp (140kW) @ 2,600 rpm

Max Torque Nm (Kgm) @ rpm

510 hp (52 kW) @ 1,600 rpm
