HEAVY DUTY TRUCKS


ISUZU D-MAX SINGLE CABIN

MY19_D-MAX 250_HO_DC_MID-AB_4X4_RHD_3QFL_DSC2845_edited.png

ISUZU D-MAX DOUBLE CAB

ISUZU D-MAX
SINGLE CAB 1.9L


ISUZU D-MAX
DOUBLE CAB LS


ISUZU DMAX
DC 3.0 Ddi 4X4 LSE A/T

FvZ 34T
CARGO CHASSIS

Gross Weight

26,000kg


FVZ 34N
TIPPER CHASSIS

Payload

18 Tons

7th Generation F Series Brochure -3.jpg

Load Body Length

Displacement

Engine Type

Max Output

Max Torque

Cab to Chassis End

Diesel

Manual

hp (kW) @ rpm

Nm (kW) @ rpm

5560 mm

7790 cc

6 Cylinder, Common Rail Turbo-Intercooler

280 hp (206 kW) @ 2,400 rpm

882 hp (90 kW) @ 1,450 rpm

F-Series trucks hold all the aces in the heavy commercial vehicle segment providing class leading economy, safety and environmental care in a package that is tailor made to meet the demands of operators. Providing the right options to meet the most demanding requirements from freight carriers and compactors to medium haul operations and off-road applications. Every businessman wants to optimize payload per trip and What better way to do this with a rigid chassis and optimal wheelbase dimensions in the 7th Generation F series trucks. As they cover the distance, they are engineered to handle heavy loads and a broad variety of rear bodies.

ISUZU FVZ SPECIFICATIONS

Fuel Tank Capacity (litres)

370

Gross Weight

26000kg

Overall Height

2950 mm

Overall Length

9750 mm

Payload

18,000 kg

Overall Width

2400 mm

Wheelbase

6350  mm

Tiltable cabin

Yes

Brakes

Drum Brakes

Front Suspension

Multi Leaf Spring Shock Absorbers - Double acting

Rear Suspension

Multi Leaf Spring withHelper Spring

Parking brakes

Yes

Seat Type

Standard

Tyre Size

12.00R22.5

Axle Layout

6x4

Operation

Power

Tilt

Standard

Engine

Diesel 6 cylinder , Common Rail Turbocharged with Intercooler

Fuel Type

Diesel

Displacement

7790 cc

Max Output hp (kW) @ rpm

280 bhp (206kW) @ 2,400 rpm

Max Torque Nm (Kgm) @ rpm

882 hp (90 kW) @ 1,450 rpm

GALLERY

IDEAL APPLICATION
